One owner, excellent condition, original packaging included. Three month warranty. (Remote control included)
Meticulously designed from the ground up.
Bringing to the fore a passion for music, technological expertise and desire to provide the ultimate sonic experience, Yamaha engineers have redefined how a high-end Amplifier should perform.
Rigid Streamlined Construction - provides strict anti-vibration protection and enables shortest cabling routes
Large toroidal transformer, solidly mounted with independent three-dimensional inner frame
Comprehensive low impedance design, shortened signal paths and copper-plated chassis
6 mm thick top panel made of non-magnetic aluminium plate
Left-right symmetrical design for independent pre amp and power amp blocks
Floating and Balanced Power Amplifier with MOSFETs
All-stage balanced transmission
Direct drawing toroidal transformer for complete elimination of signal transmission loss
Exceptionally low impedance through secure screw connections
Superior quality electronic volume control for optimum sound
Discretely configured phono amp
Exquisite, large level meters reflect the dynamics in the music
Meticulously designed and beautiful in appearance - just like a musical instrument
Original speaker terminals for high sound quality, as well as beauty and ease of use
Obsessive, meticulous switch design - elaborate, richly textured and easy-to-use.
|Maximum Power (4 ohms, 1kHz, 0.7% THD, for Europe)||170 W + 170 W|
|High Dynamic Power/Channel (8/6/4/2 ohms)||120/150/200/300 W|
|Frequency Response||5 Hz-100 kHz (+0 dB/-3 dB)|
|RIAA Equalization Deviation||20 Hz-20 kHz +/-0.5 dB|
|Total Harmonic Distortion (CD to Sp Out, 20 Hz-20 kHz)||0.025%|
|Signal-to-Noise Ratio (CD)||103 dB (S: 200 mV)|
|Input Sensitivity (CD)||200mV/47k ohms|
|Dimensions (W x H x D)||435 x 180 x 464 mm; 17-1/8” x 7-1/8” x 18-1/4”|
|Weight||24.6 kg; 54.2 lbs.|
- Fully balanced circuitry to deliver impressively low signal-to-noise ratio and improved channel separation
- Large toroidal transformer in the pursuit of pure musicality
- Mechanical Ground Concept maximizes rigidity and reduces unwanted vibration
- High-quality PPS capacitors for delivering an authentically musical sound
- Exquisite level meters visually present the dynamics and pulse of the music
- Obsessive, meticulous switch design
- Heavy-duty brass feet with spikes or scratch-resistant base
- Original speaker terminals cut from pure brass with highly secure connection
Maximum Power (4 ohms, 1kHz, 0.7% THD, for Europe) 170 W + 170 W
High Dynamic Power/Channel (8/6/4/2 ohms) 120/150/200/300 W
Rated Output Power [20 Hz-20 kHz, 0.07 %THD] 100 W ＋ 100 W (8 ohms), 150 W ＋ 150 W (4 ohms）
Damping Factor ≧ 250 (1 kHz, 8 ohms)
Frequency Response +0 /-3 dB (5 Hz-100 kHz) , ＋0 / -0.3 dB (20 Hz-20 kHz)
RIAA Equalization Deviation ＋/-0.5 dB (PHONO (MM/MC))
Total Harmonic Distortion (20Hz to 20kHz) [Input 0.5 V] PHONO MC→LINE2 OUT: 0.02 % (1.2 mVrms), PHONO→LINE2 OUT: 0.005 % (1.2 Vrms), CD, etc./BAL1,2 →SP OUT: 0.035 % (50 W/8 ohms)
Signal-to-Noise Ratio PHONO MC: 90 db, PHONO MM: 96 dB, CD, etc.: 110 dB, BAL1,2: 114 dB
Input Sensitivity [1 kHz, 100 W/8 ohms] PHONO MC: 150 uVrms/50 ohms, PHONO MM: 3.5 mVrms/47 kohms, CD, etc.: 200 mVrms/47 kohms, MAIN IN: 1 Vrms/47 kohms, BAL1,2: 200 mVrms/100 kohms
Transformer 623 VA (Toroidal)
Dimensions (W x H x D) 435×180×464 mm; 17-1/8" x 7-1/8" x 18-1/4"
Weight 24.7 kg; 54.5 lbs
