DirectStream is one of the most remarkable DACS ever built as all the major reviewers agree. Hand written, discrete, perfection based conversion that uncovers all the missing information hiding in your digital audio media. CD’s, streaming audio, high-resolution PCM or DSD based media are expertly upsampled in the DirectStream to twenty times DSD rate and output as pure analog directly into your amplifier or preamplifier. There has never been a better sounding DAC at anywhere close to the price of DirectStream. It is the first choice of thousands of critical listeners worldwide, and with its ability to accept our free Operating System upgrades, will never become obsolete.
- 100% DSD BASED D-A CONVERTER
- UPGRADABLE VIA SOFTWARE RELEASES
- VOLUME, BALANCE CONTROL BUILT IN
- UPSAMPLES PCM AND DSD TO 20x DSD RATE
- DXD SUPPORT
- PASSIVE TRANSFORMER COUPLED OUTPUT
- IMPROVES IMAGING + SOUNDSTAGE
- DIRECT SIGNAL PASS WITH 1x MASTER CLOCK
- HANDWRITTEN FILTERS, PROCESSORS, SAMPLERS
- IMMUNE TO OUTSIDE SOURCE JITTER PROBLEMS
- INCREASED DIGITAL HEADROOM
- NO OFF-THE-SHELF IC-DAC CHIPS USED
- UNCOVERS DETAILS USUALLY MASKED BY PCM PROCESSORS
- 7x DIGITAL INPUTS
- MQA + TIDAL READY WITH OPTIONAL BRIDGE II
- FULLY BALANCED FROM INPUT TO OUTPUT
- COLOUR TOUCH SCREEN
Unit Weight: 22 lbs [9.97 kg]
Unit Dimensions: 14” x 17” x 4” [ 36cm x 43cm x 10cm]
Shipping Weight: 31 lbs [14 kg]
Shipping Dimensions: 20.5”x 24” x 10” [52cm x 61cm x 25cm]
Input Power: Model specific 100VAC, 120VAC, or 230VAC 50 or 60Hz
Power Consumption: 30W
Digital audio inputs
I2S(2), Coax, XLR Balanced, TOSLINK, USB, Network Bridge slot
I2S, and USB — 44.1kHz to 352.8kHz 16bit, 24bit, DSD 64, DSD 128 (I2S DSD 256 with Sunlight update)
TOSLINK – 44.1kHz to 96kHz 16bit, 24bit
XLR (AES/EBU)S/PDIF (coax)– 44.1kHz to 192kHz 16bit, 24bit, DSD 64
Analog Audio Output
Connector: RCA/XLR Unbalanced /Balanced (X2)
Output level, low: 0.282 VRMS Balanced, 0.141 VRMS Single Ended
Output level high, maximum: 2.818 VRMS Balanced, 1.414 VRMS Single Ended
Output Impedance: 100Ω/200Ω
Frequency Response: 20-20KHz +/- 0.25dB
THD&IM @ 1KHz (full scale): <0.03%
Output Stage: Passive audio transformer, fed by high current, high speed analog amps producing double rate DSD.
Format: PCM or DSD
Sample rate: (PCM) 44.1kHz, 48.0kHz, 88.2kHz, 96.0kHz, 176.4kHz, 192kHz, 352.8kHz
Word length (PCM): 16b, 18b, 20b, 24b
Data rate (DSD): Standard (2.8MHz) or Double (5.6MHz) DoP as well as raw DSD on I2S and USB inputs
Input jitter reduction: effectively 100%, residual immeasurable. No input PLLs, FLLs.
Input Processing: 170MHz
Signal Processing: 50MHz
Synchronous Upsampling, all inputs: 28.224MHz
Digital Processing S/N ration" >146 dB
Digital Volume Control: Zero loss of precision
Analog Conversion method: Delta Sigma (DSD) Single-bit double rate
I2S Digital Input
Format: PCM or DSD. DoP on all inputs as well as raw DSD on I2S inputs
USB Digital Input
Connector: USB “B” Type
Format: PCM or DoP v1.1 (DSD over PCM)
Transfer mode: Asynchronous
The Absolute Sound Review
Easily the best DAC I've ever heard in my system
"DirectStream's easily the best DAC I've ever heard in my system, making digitally-recorded music sound better than I've ever heard it."
PS Audio achieves the impossible
"The DS is a game changer; I think it has caused the ‘war' between DSD and PCM to be on hold or mute for most of us, and above all hold your horses before buying expensive high-resolution PCM files or DSD. That alone is a major accomplishment."
6 Moons Review
The best way we've yet encountered to turn digital into music
"But what happened now was beyond our expectations. Maybe we had been lulled into a bit of been-there-done-that reviewer fatigue but the DirectStream's handling of this CD became a rude wakeup call and put us back on edge to eat crow. Damn, the performances of the various groups and soloists were so real and at such dynamic range, it was hard to believe that the source material was a simple 16/44.1 Redbook CD."
There was an amazing sense of purity to the DirectStream's way with music as if everything and anything extraneous had been stripped away.
"Even at low listening levels, music retained its character with no sense of the sound washing out. For those people looking for a direct-to-amp DAC/Digital Preamp, consider the DirectStream a solid contender."
Stereo Times Review
the PS Audio DirectStream is the most musically and technically capable device of any type that I've ever had the pleasure to evaluate
"After listening to the PS Audio PerfectWave DirectStream DAC for the past few months it is my opinion that DirectStream represents a new benchmark in audio reproduction. Notice that I didn't say "digital audio reproduction." In other words, in my view the PS Audio DirectStream is the most musically and technically capable device of any type that I've ever had the pleasure to evaluate. My heartfelt congratulations go out to Paul McGowan, Ted Smith, and PS Audio's excellent design team for making DirectStream a reality for those of us who truly love our music."
Positive Feedback Review
this bloody DAC, DSD to the fore, is a real killer. Flat-out, stone-cold, and damn-straight
"This is a brilliant design, with exceptional execution, and paradigm-setting sound.
I can tell you, this bloody DAC, DSD to the fore, is a real killer. Flat-out, stone-cold, and damn-straight.
It has been a while since 2008, but now I have to say that the DirectStream DAC is the first real rival to Playback Designs that I've heard. It goes right to the top of my heap of DSD DACs, right next door to the PD Series-3. The envelope for the audio arts has moved out yet again. To tell you the truth, I couldn't be more pleased! This is good for music, for our recordings, and for us all.
And that is the highest compliment that I can pay to PS Audio's breakthrough product...."
"...Performance is on par with some of the very best “traditional” designs on the market, and with its potential for endless upgradability, the DirectStream is revolutionary.
