Outdoor speaker systems that combine quality and durability, and provide a wide variety of installation options. Yamaha's advanced speaker technology makes it possible to combine high sound quality with long-term durability. Unique angled cabinet design blends in with external and interior décors.
Two-way acoustic suspension design
High-grade weatherproof cabinets with special processing for drip, water and UV resistance
Precise sound imaging supported by time-aligned woofer and tweeter placement
Flexible installation options with supplied mounting brackets
Weather resistant 5-way binding post speaker terminals
Powder-coated aluminum speaker grilles
Supplied rubber feet for desktop/bookshelf placement
Wide range of applications for home theaters, small commercial spaces and public buildings
Durability
• High-grade weatherproof cabinets with special processing for drip, water and UV resistance New waterproof woofer and soft dome tweeter• Weather resistant 5-way binding post speaker terminals• Powder-coated aluminium speaker grilles
Premium Sound Quality and Design
• Yamaha's advanced speaker technology makes it possible to combine high sound quality with long-term durability• Unique angled cabinet design blends in with external and interior décors• Two-way acoustic suspension design— New waterproof woofer for accurate mid/low frequency response— Fluid-cooled, coated soft dome tweeter for clear high frequency sound— Waveguide and front baffle for wide sound dispersion• Precise sound imaging supported by time-aligned woofer and tweeter placement
Versatility
• Supplied mounting brackets allow the speakers to be mounted on the wall or on the ceiling, with either end facing up, or even horizontally, with a 90° adjustment range Install the NSAW992, NSAW592, NSAW392 all-weather speakers on the wall or the ceiling• Supplied rubber feet for desktop/bookshelf placement• Wide range of applications for home theatres, small commercial spaces and public buildings
Specifications
Type 2-way acoustic suspension
Woofers 13cm (5-1/4") waterproof cone
Tweeter 2.5cm (1") fluid-cooled, coated soft dome
Frequency Response 60 Hz –25 kHz
Nominal Input Power 40 W
Maximum Input Power 120 W
Sensitivity 86 dB/2.83 V/1 m
Crossover Frequencies 6 kHz
Impedance 6 ohms
Dimensions (W x H x D) 170 x 273 x 136 mm(6-3/4” x 10-3/4” x 5-3/8”)
Weight 1.8 kg; 4 lbs./unit
