Description
- Dedicated moving coil phono stage
- Simple connectivity and operation
- Fully adjustable via DIP switches located on the rear panel
- MUSE operational amplifier used in RIAA equalization amplifier
- Two selectable gain settings
- Default factory settings matched for all Rega MC models
- Latest design custom casework
- Lifetime warranty against manufacture defects
Output Impedance
200 Ω
Recommended Minimum Output Load Resistance
5 k
Frequency Response (50 kΩ Output Load)
13 Hz (-3 dB) to 100 kHz (-0.3 dB)
RIAA Accuracy (50 kΩ Output Load)
Better than ±0.2 dB 100 Hz to 100 kHz
Power Requirements
24 V AC at 150 mA maximum
Input Sensitivity (for 200 mV Output)
4 off = 133 uV / 4 on = 67 uV
Input Loading Resistance
1 and 2 off = 400 Ω / 1 on = 100 Ω / 2 on = 150 Ω / 1 and 2 on = 70 Ω
Input Loading Capacitance
3 off = 1000 pF / 3 on = 4300 pF / Gain (at 1 kHz) / 4 off = 63.5 dB / 4 on = 69.5 dB
Maximum Input Level (at 1 kHz)
4 off = 6.7 mV / 4 on = 3.4 mV
Factory settings for all Rega MC cartridges
Impedance 100 Ω / Capacitance 1000 pF / Gain Setting High
Since humble beginnings back in 1973 Rega’s initial success was built upon award-winning tonearms and turntables but Rega has been making complete hi-fi systems since the eighties.
Engineering has always been the beating heart of Rega Research, a company obsessed with specialist materials, tolerances and accuracy.
From day one every Rega product has been designed to achieve the best musical performance and deliver a lifetime of musical enjoyment at an affordable price.
To this day, Rega remains a dedicated British manufacturer and now employs over 140 people selling to 46 different countries.
We manufacture a vast range of hi-fi products including amplifiers, phono stages, cartridges, CD players, loudspeakers, and a wide range of accessories to name but a few. Rega designs and assembles every product by hand in our custom-built 38,000 square foot facility in the South East of England, using a team of highly trained and highly skilled technicians who take great pride in the work they do.
So confident are we in our ability, Rega offers a lifetime warranty against manufacture defects on every single product we make.
