Description
Specifications:
- Maximum Power Output: 350 watts/ch (4 ohms)
- Continuous Power Output: 200 watts/ch (8 ohms)
- Total Harmonic Distortion: < 0.0075>#/li###
- Intermodulation Distortion (60 Hz : 7kHz, 4:1): < 0.03>#/li###
- Frequency Response
- Phono Input 20 Hz - 20k Hz, 0 ± 0.5 dB
- Line Level Inputs 10 Hz - 100k Hz, 0 ± 0.5 dB
- Damping Factor 600 (20 Hz - 20 kHz, 8 ohms)
- Input Sensitivity / Impedance
- Phono Input (MM) 5.2 mV / 47k ohms
- Line Level Inputs (RCA) 340 mV / 5.6k ohms
- Line Level Inputs (XLR) 540 mV / 100k ohms
- Signal to Noise Ratio (IHF A-weighted)
- Phono Input (MM) 80 dB
- Line Level Inputs 103 dB
- Digital to Analog Converters: Texas Instruments
Digital Section
- Frequency Response: 10 Hz - 90k Hz (0 ± 2 dB, Max)
- Signal to Noise Ratio (IHF A-weighted): 102 dB
- Input Sensitivity/Impedance: 0 dBfs / 75 ohms
- Preamplifier Output Level: 1.43 V (at -20 dB)
- Coaxial/Optical Digital Signals: SPDIF LPCM (up to 24-bit / 192k Hz)
- PC-USB:
- USB Audio Class 2.0 (up to 32-bit / 384k Hz) (Driver installation required)
- Support MQA and MQA Studio (up to 24-bit / 384k Hz )
- Roon Tested
For over six decades Rotel has been engineering, manufacturing, and delivering audio products built to the highest standards of quality, with extraordinary performance and exceptional value. This Japanese family owned, and family operated business leverages the tradition and heritage of this 60-Year old icon brand supported by innovation and passion delivering products proud to wear the Rotel badge building our ever-growing extended Rotel family of customers including audiophiles, music lovers, musicians, recording artists and loyal fans.
