Description
- Inputs:
- 1 x USB PCM / DSD Digital (PCM up to 384kHz & DSD up to DSD256 )
- 1 x Coaxial Digital S/PDIF (PCM up to 192KHz supporting DoP format DSD64)
- 1 x Optical Digital S/PDIF (PCM up to 192KHz supporting DoP format DSD64)
- 1 x Bluetooth or WiFi receiver module (optional).
- 1 x AES balance XLR (PCM up to 192KHz)
- 1 x Analog Stereo RCA (does not go through A2D conversion, analog input is selected by the preamp directly to analog outputs)
- Outputs:
- 1 x pair of stereo RCA out (max output 4V)
- 1 x pair of stereo XLR balanced out (max output 8V)
- 1 x Optical S/DPIF out
- USB Sampling Rates: 44.1KHz, 48KHz, 88.2KHz, 96KHz, 176.4KHz, 192KHz, 352.8KHz, 384KHz and DSD 2.8MHz(64), 5.6MHz(128), 11.2MHz(256)
- S/PDIF Sampling Rates: 44.1KHz, 48KHz, 88.2KHz, 96, 176.4KHz, 192KHz, 352.8KHZ, 384KHz (Coaxial)
- Bit Resolution: 16-32-bits
- THD+N: 0.0015>#/li###
- Dynamic range: >-113dB
- Frequency Response: 10Hz to 80kHz
- Dimensions: 235 mm W x 281 mm D x 55 mm H (including feet)
- Weight: 2.3Kg
- Worldwide AC voltage: (90VAC~130VAC // 210VAC~ 250VAC) With Voltage Select Switch
- AC Fuse: Slow-blow, 1A, 250VA
